Battle Damage Part 2
Posted by: Gerald Voigt in How-To, Progressive Model Build, tags: battle damage
I dug through my spares stash for a couple of the old IMC combat damaged parts to show how a more realistic 3D battle damage can be created.
I’m going to use a wing section from a 1:48 P-51 as my demo example. This part of the series will address recessing a panel so it is flush with the surrounding surfaces. Later I will show you how to install a surface laminated method.
The first step is to select the panel area where you want to impose the battle damage to. Once you do mark it so you don’t mistake another one.

Now we need to make a master pattern. I like to use Tamiya tape since it is transparent and easily burnished to reveal the panel lines underneath. Lay a piece of tape over the area. You can also use tracing paper and a pencil to mark the panel lines.
Once you have the tape in place you can cut along the panel lines surrounding the panel you are going to
apply the inflict the damage to.
Then take either the center or the outside of the panel you cut and transfer

that onto the piece of aluminum you are going to use to make your replacement panel from.
I used the outside, but either will work. It acts as a pattern and guide for you to do your cutting. If you are really good, you’ll be able to get it exact with the first cut. I purposely made mine a bit rough so I can demo the trimming and fitting process.



Once you rough cut around the piece to be removed with a tin snips or scissors, you can go along and do the final cuts with a PE Shear in desired or needed.
After you get this panel section removed from the metal sheet, set it aside for now. Your gonna be occupied for a while as you remove the area where this panel is going to be inserted.
To make faster work of the removal of the panel I use my Dremel with various bits to grind away the plastic I need removed.


Once you have the center of the panel carved out you have two options, recess the remaining area by scrapping with a knife or remove it all the way to the edge of the panel line. I chose the latter for this demonstration.
I try to let the Dremel do most of the removal, then once close, I finish off the rest with a flat file so I have a straight uniform edge all the way around the opening.
At some point you should have a nice square opening the exact (well close anyway) size as the panel you’re going to be replacing.
You can then start to trim the metal replacement panel so it fits snuggly inside the opening with little to no gaps.
I need to work on both my opening and panel before I continue on with part three of this How-To. I’ll work on that. You start looking for reference photo or illustrations of what the insides of a Mustangs wing looks like.
In the next segment, I’ll install the panel and with luck (I haven’t done this for more than a decade or two) this panel should look like nothing was replaced.
Then we can prepaint both the outside and inside as well as add any decaling that might cover this area.
So until next time…Happy Modeling!
